600mm Vertical Heat Sealer Automatic Double Foot Pedal Operated

600mm Vertical Heat Sealer Automatic Double Foot Pedal Operated


  • Description
  • Brand
  • Additional information


Vertical Heat Sealer Size: 600mm Length x 5mm Seal width double heat. Heating element on the upper and lower jaws making this suitable for heavy duty films.
Pedestal mounted Vertical Heat Sealer with foot switch, adjustable working height from 700mm to 900mm with an adjustable heavy duty support shelf.
The vertical heat sealer is suitable for sealing bags that are required to kept upright like sacks for flowable product, liquids and powders or powders and bulky materials like gravel, aggregates or firewood.
Foot Switch Sealers provide a faster hands free sealing operation.
Supplied with stand, pedestal, adjustable worktable and spare element.
All heat sealers from PackSealer are built to the high specification and incorporate an adjustable timer control to suit a wide variety of films from 2 x 25μ (2 x 100 gauge) to 2 x 250μ (2 x 1000 gauge). Approximately up to 10 packages can be sealed per minute.

In automatic mode the sealer will close at preset intervals without the need to press the foot switch.

Picture is for information and shows the similar single heat option.

The seal width is 5mm, however a 8mm conversion is available.

To ensure that you have continued products a maintenance kit is a good optional addition.

The vertical sealer comes with a heavy duty support stand and adjustable product support tray.

Power 1500w, Weight 55kg

The PSV range of heavy duty sealers are delivered on a pallet. Weight 50kg.

Important note.

When sealing the initial load creates a spike in demand for a fraction of a second that can trip the electrical breaker.  This type of spike is common with motors when they start up. We recommend that a C type breaker is installed (commonly called motor rated) which accommodate the spike. Alternatively  a B32 type breaker.

A B type breaker may trip when the voltage goes over the limit for 100 milliseconds and the C type work on a longer time period before they trip.  This heat sealer can go over the 20amp (B20) for more than 100 milliseconds but not over 32 amp (B32).



Since the year 2000 Packsealer has offered an enormous range of heat sealers, vacuum sealers, rotary band sealers, and packaging equipment the Pack Sealer branded machines are a cost effective alternative to the European manufactured equipment. PackSealer heat sealers; impulse heat sealer, direct or constant heat sealers and band sealers plus all the necessary spare parts to maintain these sealers. The impulse sealers include the simple manually operated hand sealers and foot sealers where the jaws are closed manually so are suited for low volume applications and automatic foot switch operated sealers for medium volume applications.  The foot pedal and foot switch are also available as double heated elements for heavy duty bags and the vertical sealer is great for sealing liquids and large heavy sacks. For high volume the rotary band sealers are the Pack Sealer machines that should be considered. All these are manufactured in stainless steel and are a fraction of the Audion prices. Spare parts are stocked; element wires, Teflon (PTFE), silicon pressure pads, cutter blades and fuses.
